Moline Bearing
PX12 2-BOLT PILLOW BLOCK MEDIUM DUTY BALL BEARING HOUSING
Pricing and availability are confirmed by our sales team after a quote request is submitted. Add this item to your quote and we'll respond with lead time and pricing within one business day.
Medium Duty UCX·2-Bolt Pillow Block

PX12 2-BOLT PILLOW BLOCK MEDIUM DUTY BALL BEARING HOUSING

11261207

The PX12 Medium Duty UCX 2-Bolt Pillow Block Housing is Moline Bearing Company part 11261207, the housing on its own with no insert: Class 30 cast iron, painted, for UCX-style (set screw locking) inserts fitting 2 3⁄8", 2 7⁄16" shafts. Ordered as a replacement housing or to pair with your own insert.

Part Number
11261207
Series
Medium Duty UCX
Housing Type
2-Bolt Pillow Block
Shaft Size
0" (0″ / 0 mm)
Weight
13.15 lb
Housing Number
PX12
PDF Catalog
Product Family
Ball Bearing
Housing Material
Class 30 Cast Iron
Housing Coating
Standard Painted

Similar Products

PX08 2-BOLT PILLOW BLOCK MEDIUM DUTY BALL BEARING HOUSING
PX08 2-BOLT PILLOW BLOCK MEDIUM DUTY BALL BEARING HOUSING
11261108
0"
PX10 2-BOLT PILLOW BLOCK MEDIUM DUTY BALL BEARING HOUSING
PX10 2-BOLT PILLOW BLOCK MEDIUM DUTY BALL BEARING HOUSING
11261115
0"
PX17 2-BOLT PILLOW BLOCK MEDIUM DUTY BALL BEARING HOUSING
PX17 2-BOLT PILLOW BLOCK MEDIUM DUTY BALL BEARING HOUSING
11261307
0"
PX13 2-BOLT PILLOW BLOCK MEDIUM DUTY BALL BEARING HOUSING
PX13 2-BOLT PILLOW BLOCK MEDIUM DUTY BALL BEARING HOUSING
11261208
0"
PX11 2-BOLT PILLOW BLOCK MEDIUM DUTY BALL BEARING HOUSING
PX11 2-BOLT PILLOW BLOCK MEDIUM DUTY BALL BEARING HOUSING
11261203
0"
PX07 2-BOLT PILLOW BLOCK MEDIUM DUTY BALL BEARING HOUSING
PX07 2-BOLT PILLOW BLOCK MEDIUM DUTY BALL BEARING HOUSING
11261107
0"

PX12 2-BOLT PILLOW BLOCK MEDIUM DUTY BALL BEARING HOUSING

The PX12 Medium Duty UCX 2-Bolt Pillow Block Housing is Moline Bearing Company part 11261207, the housing on its own with no bearing insert: Class 30 cast iron with a standard painted finish. It is ordered as a replacement for a damaged housing, or to pair with a separately specified insert.

Fits

With the right insert it takes 2 3⁄8", 2 7⁄16" shafts, using UCX-style (set screw locking) inserts (UCX12-38, UCX12-39). Complete units built on this housing: 29421206, 29421207.

Shipping weight: 13.15 lb.

Applications

These units are manufactured overseas for Moline Bearing Company to the quality standard set by the bearing industry, at a lower price. Medium Duty ball bearing units go into drives that outgrow a normal-duty unit but do not need a roller bearing: conveying, screening, material handling, and food and beverage equipment. It is dimensionally interchangeable with industry-standard UCX-series units of the same size.
